Largest Touch Screen Monitor Capacitive Touch | Ever Glory

Specifications:

Solutions to Glare and Reflection Issues
1.Full Lamination with Optical Clear Adhesive，eliminates air gaps between layers, fundamentally reducing interface reflection. It greatly improves contrast ratio and outdoor visibility of displays.

2.The anti-reflection coating lowers mirror reflection of cover glass, effectively reducing ambient glare and ghost reflections. It also increases light transmittance, ideal for cover and protective glass applications.

3.Applying matte frosting treatment to glass scatters direct strong light, resolving direct glare issues and avoiding washed-out display visuals. The combination with anti-reflection (AR) film achieves superior overall effects.

4.Combines oil-repellent and anti-fingerprint properties while mitigating subtle diffuse reflection, ideal for touch-control products.

5.Equip external light hoods, raise bezels and adjust screen tilt angles to avoid direct front strong light. This is a cost-effective auxiliary solution.

Solutions to UV Aging Issues for Outdoor Use
1.Add UV-resistant film layers on glass surfaces to block short-wave ultraviolet penetration and prevent light source erosion from outside. Suitable for outdoor and open-air equipment.

2.Incorporate UV absorbers into the cover glass substrate. Combined with coatings, it creates double protection, perfect for devices exposed to intense sunlight outdoors long-term.

3.Upgrade standard AG and AR films to weather-resistant formulations. Conventional coatings tend to peel and fail due to UV aging, while specialized coatings retain stable light transmittance and anti-glare performance for long-term use.

4.Install sun visors, outer enclosures and protective panels on the device to reduce direct sunlight exposure.

5.Seal bezels and gaps with UV-resistant silicone and waterproof adhesive to prevent ultraviolet rays from invading internal components and adhesive layers from the sides.

Solutions to Rain-induced False Touches
1.AF Oleophobic & Hydrophobic Coating: Increases the water contact angle of the surface, making water droplets bead up and slide off rapidly. It prevents water film spreading and reduces electric field interference.

2.Dual composite coating: AF plus anti-condensation coating. It copes with high humidity and continuous rainy conditions, preventing thin water film adhesion.

3.The device is rated IP65/IP67 for waterproof performance. Waterproof gaskets and water-resistant adhesive are used to seal bezels, ports and lamination gaps, preventing rainwater and moisture from seeping into the display unit.

4.Design drainage grooves on cover glass edges and install the screen at an angle to guide water away quickly and prevent water pooling on the touch area.

5.Add an insulating protective layer to the touch sensor to isolate leakage interference caused by moisture and water stains.

6.Enable dedicated waterproof and anti-fog algorithms. They identify capacitive characteristics of water droplets and continuous water films, actively block invalid touches and bring false touch rate down to the standard level.

7.Adopt zoned touch strategy. It distinguishes signals from single-finger touches and large-area water films, suppressing full-area dead zones and erratic touch points.

8.Dynamic adaptive threshold: Automatically adjust touch sensing thresholds as humidity rises to adapt to humid environments.

FAQ
1.Q: Will rain and water droplets cause false touches on the touch screen?
A: No. We adopt AF composite coatings, drainage structure and professional anti-false-touch algorithms to effectively avoid false touches caused by water.

2.Q: What solutions are used for touch screens in long-term rainy and high-humidity environments?
A: We combine AF+anti-condensation dual coatings, IP65/IP67 waterproof structure and adaptive touch algorithms to suit harsh humid conditions.

3.Q: How does the zoned touch strategy work against water interference?
A: It differentiates finger touch signals from large-area water film signals, preventing dead zones and erratic touch points.

4.Q: Can the touch performance stay stable when humidity changes greatly?
A: Yes. The dynamic adaptive threshold automatically calibrates sensing sensitivity to adapt to varying humidity.

5.Q: Besides coatings and algorithms, what structural designs help prevent water trouble?
A: Drainage grooves on cover glass, tilted screen installation and waterproof sealing for gaps and ports are applied to drain water and block moisture intrusion.
